Lilliput Q17 17.3" 12G-SDI/HDMI HDR Monitor (Gold Mount)

Model #Q17-ABBP

Prices

New

~£1,177.39

Buy

Converted - As of 10:26 UTC -

Check

Buy

As of 2025-09-30 08:27 UTC -

Specs

Brightness

300 nits

Native Resolution

1920 x 1080

Video Input & Output

2x BNC (12G-SDI) Input
2x BNC (3G-SDI) Input
1x HDMI 2.0 Input
2x BNC (12G-SDI) Loop Output
2x BNC (3G-SDI) Loop Output
1x HDMI 2.0 Loop Output

Display Type

IPS-Type LCD

Display Size

17.3" / 43.9 cm

Aspect Ratio

16:9

Touchscreen

HDR Support

Yes

Pixels Per Inch

127 ppi

Image Control

Anamorphic De-Squeeze, Blue Only, Check Field, Color Temperature Selection, False Color, Focus Peaking, Histogram, Image Flip, Pixel-to-Pixel Zoom, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra

Audio Input & Output

1x 1/8" / 3.5 mm Headphone Output

Embedded Audio

SDI: 16-Channel
HDMI: 8-Channel

Video Format

SDI
UHD 4K: 60/50/30/25/24
1080p: 60/50/30/25/24
1080PsF: 30/25/24
1080i: 60/50
720p: 60/50
HDMI
UHD 4K: 60/50/30/25/24
1080p: 60/50/30/25/24
1080i: 60/50
720p: 60/50

Media Slot

Battery Type

1x Gold Mount

Power Input & Output

1x XLR 4-Pin (15 VDC) Input

Other Input & Output

1x RJ45 (GPI) Input
1x RJ45 (LAN) Input
1x RJ45 (RS-422) Input
1x RJ45 (RS-422) Output

Wi-Fi Compatibility

Bluetooth Compatibility

Input Power

12 to 24 VDC

Dimensions

17.1 x 10.4 x 2.1" / 434 x 263 x 54 mm

Weight

7.1 lb / 3.2 kg

Lilliput Q17 17.3" 12G-SDI/HDMI HDR Monitor (Gold Mount)

0 Reviews
